Warranty :
1 Year
Description
Key Specifications
| Feature | Specification Details |
|---|---|
| Analog Video Input | 16-ch BNC interfaces supporting HDTVI, AHD, CVI, and CVBS |
| IP Video Input | 8-ch default (expandable up to 32-ch in Enhanced IP Mode), up to 8 MP resolution |
| Encoding Capability | Main stream: 8 MP @ 8 fps, 3K @ 12 fps, 5 MP @ 12 fps, 4 MP @ 15 fps |
| Video Compression | H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 |
| Storage Interface | 2 SATA interfaces, supporting up to 10 TB capacity per HDD |
| Video Outputs | 1-ch HDMI (up to 4K / 3840×2160), 1-ch VGA (1080p), 1-ch CVBS BNC |
| Network Interface | 1x RJ45 10/100/1000 Mbps self-adaptive Gigabit Ethernet |
| USB Interfaces | 1× USB 2.0 (Front); 1× USB 3.0 (Rear) |
